| Model Number: | HX40 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Packaging Details: | neutral packing |
| Delivery Time: | 3-7 days |
| Payment Terms: | TT ,western union ,paypal |
| Supply Ability: | 1000pcs |
| Size: | 56.00/83.03mm | Type: | Turbochargers |
|---|
1. MODEL:HX40 forward
2. HX40 3599593 56.00/83.03mm 7+7 blades high performance turbocharger billet/milling/aluminum 2618 compressor wheel for 3534921/4035626/3532494/3597501
Size:
Nose diameter:13.91mm
inducer:56.00mm
Exducer:83.03mm
Tapered tip exducer:88.22mm
Tip height:5.50mm
Superback:5.01mm
Bore size:7.00mm
Blade height:32.86mm
cutback:0.00
splitter height:21.85mm
sp height angle:-9.40
Overall height:39.76mm
7+7 blades
Bore type:through
trailing angle:60 degree
Tapered tip angle:30 degree
it is for OE compressor housing
4.High quality and competitive price.
5.Any questions please send email to me.
6.Application:
3534921
4035626
3532494
3597501
All the compressor wheels have been balanced.
we can produce as your requirement ,the minimun order is 5pcs
